STEEL | Plates and Coils

▪   ASTM : A36 / A572 / A573 / A633 / A656 / A709 / A242 Type 1 / A588 Grade A / A283 / A285 Grade A, B, C, D / A515 Grade 60, 65, 70 / A516 Grade 55, 60, 65, 70 / A537 Class 1, 2 / A387 Grade 11 Class 1, 2 / A387 Grade 12 Class 1, 2 / A387 Grade 22 Class 1, 2 / A204 A, B, C / A131 / AH32 / DH32 / EH32 / AH36 / DH36 / EH36 / A517 Grade F

▪   EN10025 : S235 / S275 / S355 / S420 / S460 / S690QL / S890QL / S960QL

▪   EN10028 : P235GH / P295GH / P355GH / P355 / P420 / P460 M, ML1, ML2

▪   LRS / ABS / DNV : A / B / D / AH32 / DH32 / EH32 / AH36 / DH36 / EH36 and equivalent

▪   API : 5L Grade B / X-42 /, X-46 / X-52 / X-56 / X-60 / X-65 / X-70 / X-80 (Sweet and Sour service)

▪   API : 2H Grade 50, 60 / 2W Grade 50, 60 / 2Y Grade 50, 60

▪   ROCKHARD : 400 / 450 / 500

▪   CAT : 1E1247 / 1E0170 / 1E1863 / 1E1839 / 1E0577

▪   SAE : 1006 / 1008

Supply Conditions

▪   As rolled

▪   Normalised rolled

▪   Thermo mechanically controlled process

▪   Quenched and tempered

▪   Furnace normalised

Discrete Plates

▪   Width (mm) : 1500 - 5000 / (in) : 59 - 197

▪   Thickness (mm) : 5 - 150 (* > 150 can be discussed) / (in) : 0.2 - 6

▪   Maximum length (m) : 24 / (ft) : 79

▪   Maximum coil weight (mt) : 25 / (tn) : 26

▪   Maximum plate weight (mt) : 30 / (tn) : 33

Cut To Length Plates

▪   Width (mm) : 1500 - 2500 / (in) : 59 - 98

▪   Thickness (mm) : 8 - 25 / (in) : 0.3 - 1

▪   Length (mm) : 6000 - 12500 / (in) : 236 - 492

Hot Rolled Coils

▪   Width (mm) : 800 - 1680 / (in) : 31 - 66

▪   Thickness (mm) : 1.2 - 20 / (in) : 0.05 - 0.78

▪   Maximum coil weight (mt) : 36 / (tn) : 40
